The N-Series connector is a medium power connector with a threaded connection and is one of the most widely used connectors.
It can be used at frequencies up to 18 GHz and are characterised by high shock resistance, high reliability and excellent mechanical and electrical properties in accordance with US military standard MIL-C-39012.
| Electrical Performance | |
|---|---|
| Characteristic impedance | 50 Ω |
| Frequency range | 0-18 GHz |
| Operating voltage | 1000 V(rms) |
| Dielectric withstanding voltage | 2500 V(rms) |
| Conductor resistance | inner conductor: ≤1.0 mΩ (initial value) |
| Outer conductor: ≤0.2 mΩ (initial value) | |
| Insulation resistance | ≥5000 MΩ |
| VSWR | S Type: ≤1.30 (typical value) |
| R Type: ≤1.35 (typical value) | |
| Mechanical Characteristics | |
|---|---|
| Central needle insertion force | ≤2 lbs |
| Center needle pullout force | ≥2 ounce |
| Center pin retention | ≥6 lbs |
| Durability | 500 cycles |
