Nbend Series
Nbend series is high performance semi-flexible replacement cable. It is more flexible than ordinary semi-flexible cable. The outer conductor of Nbend is helical wrap of silver-plated copper. The helical tape outer conductor minimized electrical length while bending and achieve lower loss. Nbend has been widely used for microwave interconnection, RF test and commercial telecom
Product Structure
Center Conductor Silver plated copper
Dielectric Solid PTFE
Outer Conductor Silver plated copper
Outer shield Silver plated copper
Outer Jacket Blue FEP
Features and Advantages
  • Up to 40GHz
  • Cost-effective
  • Low loss
  • Good mechanical phase stability
Typical Applications
  • Microwave interconnection
  • Commercial Telecommunications
  • RF testing
